Minicom Smart 8 Port CAT5 KVM Switch
0SU22002A
The Minicom Smart 0SU22002 is a 8 port, single user Cat5 KVM switch. This sleek, 1U sized Smart CAT5 switch features CAT5 cable to eliminate cable clutter, and powerful on-screen display control and management. The 8 port CAT5 Switch supports 8 computers letting you control and operate your server room racks with just one keyboard, monitor and mouse. Rack mounting kit is included.
Note: Buy platform-specific Minicom RIC (Remote Interface Connection) cables to support PS/2, SUN, and USB, as and when you need them.
Minicom Smart CAT5 KVM Switch Diagram
Minicom 0SU22002 Features and Benefits:
- Control 8 computers from one KVM console
- RIC (Remote Interface Connection) cable technology
- Extend distance between computer and switch up to 10 m/33ft.
- Rack mountable: 1U space saving KVM switch
- Innovative CAT5 technology
- Multi-layer security protects your corporate data
- Better server management: choice of On Screen Display, serial port or push button control
- Multi-platform: PS/2, SUN, and USB support
Minicom Smart 0SU22002 Specifications:
| Mechanical | |
| Height | 1.62 in. (41.5 mm.) |
| Width | 8.44 in. (215 mm.) |
| Depth | 4.34 in. (122 mm.) |
| Weight | 2.2 lbs. (1000 g.) |
| Environmental | |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -40°C to 70°C/-40°F to 158°F |
| Power | |
| Supply | 85 - 265 VAC 50/60 Hz |
| Connections | |
| System | RJ45 |
| Serial | RJ11 |
| Local KVM | HDD15/MinDin6/MiniDin6 |
| Number of Ports | 8 |
| Resolution | Up to 1600x1200@75Hz |
| Maximum Distance | 33 ft. (10 m.) |
| System Cable | CAT5 FTP or UTP 2x4x24 AWG solid wire |
| Management | OSD, Hot Key, Push Button, Serial |
| Mouse | PS/2, Wheel mouse, Intellimouse, 5-button mouse |
| Operating System | Dos, Windows (3.1, 9x, 2000, NT4, ME, XP, 2003 Server) Linux, Unix, QNX, SGI, FreeBSD, BeOS, Open VMS, Novell 3.12-6, Alpha UNIX, HP UX, SUN |
