Avocent AutoView 1000R KVM Switch

All-in-one 16-port analog-digital KVM switch combines analog and KVM over IP access solution
The all-in-one Avocent AutoView 1000R (A1000R) switch combines analog and KVM over IP for local access from anywhere in the data center and remote IP-based access using a standard TCP/IP connection. The Avocent AutoView 1000R (A1000R) is a 16-port KVM switch that supports a local user at the rack and an IP-based user anywhere in the data center or from any location across the globe.  For complete system administration, the Avocent AVWorks advanced management software is bundled with the AutoView 1000R switch. AutoView also features the patented On-Screen Configuration and Activity Reporting (OSCAR) management tool for convenient point and click system configuration and server selection at the rack

Avocent AutoView A1000R Diagram

Avocent AutoView 1000R (A1000R) Features and Benefits:

• 16-port analog-digital KVM switch includes AVWorks software

• All CAT 5 cabling reduces cable bulk

• Operational in minutes with wizard-based installation

• Flexible access for local, extended and remote KVM over IP users

• Multi-platform support: PS/2, Sun and USB servers

• Flash upgrades for fast and easy updates

• Keep Alive maintains server functions in the event of power failure to the switch

• Switch-based authentication with password protection to each attached server

• Multi-level security with DES, 3DES and 128bit encryption

• Convenient on-screen GUI display provides real-time system status at the rack

• Advanced administration tools for setting permissions and access rights

Avocent AutoView 1000R (A1000R) Specifications:


Mechanical
Height	1.75 in. (4.45 cm)
Width	17.00 in. (43.18 cm)
Depth	11.00 in. (27.94 cm)
Weight	8 lbs. (3.6 kg)
Environmental
Operating Temperature	32 to 104 degrees F (0 to 40 degrees C)
Storage Temperature	-4 to 158 degrees F (-20 to 70 degrees C)
Power
Operating Voltage	100 to 240 VAC
Power Frequency	50 - 60 Hz Auto Sensing
Supported Hardware
Computers	IBM PC/AT, PS/2 USB, Sun and 100 compatibles
Monitor	XGA and VGA; Video Resolution-Local analog port: 1600x1280 @ 75 Hz
Peripherals	PS/2 keyboard, PS/2 mouse, microsoft Explorer mouse, Mouse IntelliMouse family
