DVNET-2P, 2X1 DVI-D, USB2.0, Audio switch
DVN-2PS
The DVN-2P is a cross-platform DVI-D switch capable of sharing one DVI-D Monitor between two computers, PC or Mac. View two computers equipped with DVI-D on a single screen, saving money and desktop space.
Applications
- Home Theater Integration
- Digital Signage Deployment
- Information Kiosks/Displays
- Film/Recording Studios
Features
- Supports Mac, PC, Linux and Sun DVI
- Supports High Resolution 1920x1200 60Hz WUXGA
- Uses universal DVI Single Link connectors
- Zero pixel loss with TMDS signal correction
- Supports all USB 2.0 Devices (Flash Drives, Printers, Cameras, Scanners, etc.)
- Supports USB 2.0 keyboard and mouse
- Balanced stereo audio output
- Front panel tactile switch with LED indicator
- Full IR and RS-232 control
SmartAVI DVN-2P Specifications
| Mechanical | |
| Height | 1.87 in. (3.81 cm) |
| Width | 10.5 in. (21.84 cm.) |
| Depth | 6 in. (13.71 cm.) |
| Weight | 5 lbs. |
| Format | DVI-D Single Line |
| Maximum Pixel Clock | 165 MHz |
| Input Interface (TX) | (2) DVI-D 29-pin (female) |
| Output Interface (RX) | (1) DVI-D 29-pin (female) |
| Resolution | Up to 1920x1200 @60Hz |
| Input/Output Cable Length | Up to 20 feet |
| Audio Frequency Response | 20 Hz to 20 kHz |
| Audio Impedance | 600 Ohm |
| Power | External 100-240 VAC/5VDC2A @10W |
UPC 813280017237
EAN 0813280017237
