Gefen Component Audio to HDMI Adapter
EXT-COMPAUD-2-HDMI
The Gefen EXT-COMPAUD-2-HDMI is a Component Audio to HDMI Adapter which allows older analog devices to be integrated seamlessly into the modern home theater. This adapter connects component video home theater devices or analog video graphic cards (VGA) to HDMI compliant digital monitors. This Gefen adapter also takes analog L+R audio and encodes it onto the HDMI signal for the full HDMI video and audio effect. With the Component Audio to HDMI Adapter legacy home theater devices and computer systems can be easily connected any HDMI display for the full digital video and audio experience.
Gefen Component Audio to HDMI Adapter Side Views
Connect the supplied VGA to Component cable to the input side of the adapter. Then connect the RCA audio cables to the audio inputs of the Component Audio to HDMI Adapter. Then connect the HDMI display or projector to the HDMI output of the Component Audio to HDMI Adapter. The adapter generates the compatible analog to digital conversion signals for video and audio as well encoding the audio onto the HDMI to make the connection between the analog inputs and the digital output work.
Gefen Component Audio to HDMI Adapter Diagram
Gefen EXT-COMPAUD-2-HDMI Features:
- Allows you to connect YPbPr HDTV sources to an HDMI display
- Encodes analog audio onto the video signal for HDMI video and audio
- Easily switch between PC/RGBHV or HDTV/YPbPr
- Supports computer resolutions up to 1920x1200 at 60Hz
- Supports HDTV resolution up to 1080p
- HDMI compliant
Gefen EXT-COMPAUD-2-HDMI Package Includes:
- Component Audio to HDMI Adapter
- One 5V Power Supply
- One 6 ft RCA L+R Audio Cable
- One 6 ft VGA to Component Cable
- Users Manual
Gefen EXT-COMPAUD-2-HDMI Specifications:
| Mechanical | |
| Height | 1 in. (2.54 cm.) |
| Width | 4 in. (10.16 cm.) |
| Depth | 4 in. (10.16 cm.) |
| Weight | 2 lbs. (0.9 kg.) |
| Power | |
| Consumption | 10 watts (max) |
| Supply | 5V DC |
| Input Signal | |
| Video | 1.2 volts p-p |
| DDC | 5 volts p-p (TTL) |
| Connectors | |
| HDMI | type A (19 pin) female |
| VGA | HD-15 female |
| Audio | analog RCA L+R |
| Amplifier Bandwidth | |
| HDMI Video | 1.65 Gbps |
| VGA | 350 Mhz |
