Gefen 8x1 DPKVM Switcher
EXT-DPKVM-841
The Gefen EXT-DPKVM-841 is an 8-input KVM Switcher for DisplayPort Video, USB, and Audio. It allows one to easily switch between eight computers using DisplayPort with the Gefen 8x1 DPKVM Switcher.
The rack-mountable Gefen 8x1 DPKVM Switcher offers an economical solution for switching between eight different computers to one display location. In addition, USB peripherals and audio are carried at the same time from each source making this a very versatile solution. Eliminating the need to purchase many displays, keyboards and other accessories for each computer in a studio or professional environment, this versatile solution saves money, supports both Mac and PC-type computers, and offers uncluttered and increased desktop space.
The 8x1 DPKVM Switcher outputs are: One DisplayPort, two USB 2.0 ports (used for keyboard, mouse and other USB 2.0 peripherals) and an analog L/R audio. This Switcher can be controlled using front-panel discrete switching, the included IR Remote control, or the RS-232 port for switching automation. The 8x1 DPKVM Switcher is compatible with all operating systems using DisplayPort and USB.
How It Works
Connect the eight included 6-foot DisplayPort cables between the computers and the Switcher inputs. Connect the eight included USB cables between the computers and the USB inputs. Connect the eight included audio cables between the computers and the audio inputs. Connect the Switcher output to the monitor using a DisplayPort cable. Connect the Switcher USB outputs to the USB peripherals. Connect the Switcher audio cables to the audio devices. Connect the included 5V DC locking power supply to the 8x1 Switcher and connect the AC power cord to an available electrical outlet. The currently selected source will be displayed.
Gefen EXT-DPKVM-841 Backview
Features:
Front-panel switching using discrete select buttons
Supports resolutions up to 2560 x 1600
Supports RGB and YCbCr color spaces
S-232 control
IR remote control
Supports USB 2.0 with backward-compatibility for USB 1.1
Jack for external IR Receiver (EXT-RMT-EXTIR)
Save space on your desktop
Rack-mountable
Gefen EXT-DPKVM-841 Diagram
Gefen EXT-DPKVM-841 Specifications:
| Mechanical | |
| Width | 17.1 in. (43.4 cm.) |
| Height | 1.75 in. (4.3 cm.) |
| Depth | 4.25 in. (10.8 cm.) |
| Weight | 12 lbs. (5.44 kgs.) |
| Maximum Pixel Clock | 360 MHz |
| Connectors | |
| Video Input Connectors | (8) DisplayPort |
| Video Output Connector | (1) DisplayPort |
| USB Input Connectors | (8) USB 2.0 Type "B" |
| USB Output Connectors | (2) USB .0 Type "A" |
| Audio Input Connectors | (8) 3.5mm analog L/R audio |
| Audio Output Connector | (1) 3.5mm analog L/R audio |
| IR Extender Connector | (1) 3.5mm analog mini-stereo |
| Audio Output Connector | (1) 3.5mm analog L/R audio (to speakers or amplifier) |
| RS-232 Control Connector | (1) DB-9, female |
| Power Supply | 5V DC, locking |
Answer: Thank you for your inquiry. This 8-port DisplayPort KVM switch uses standard DisplayPort and USB A-to-B type USB cables. The unit comes supplied with (8) x 6 ft. DisplayPort cables (CAB-DP-06MM), (8) x 6 ft. USB 2.0 cables (A - B) (CAB-USB-6), (8) x 6 ft. 3.5mm mini-stereo audio cables (CAB-AUDIO-6), and (1) AC Power Cord (CAB-POWERCORD-US). It also ships with (1) x IR Remote Control Unit (EXT-RMT-8IRN), (1) x Set Rack Ears (EXT-RACK-19-GRY), (1) x 5V DC Locking Power Supply (EXT-PS54AULP) and (1) Quick-Start Guide(QSG-DPKVM-841).
For additional assistance in placing your order, please call us toll free at 1-877-586-6654.
Question: Hi, can i get an Aust compatible power supply with it or is it switchable from 110v to 240v?
Answer: Thank you for your inquiry. We know this unit is available in other countries, but unfortunately cannot determine the different power supplies that are available.
It might be worthwhile to contact a local distributor. You can find authorized Gefen resellers on the following page http://www.gefen.com/dealers/worldmap.jsp.
