FXCore-AV FXCS-MX0408S, 4 PC x 8 User Singlemode
FXCS-MX0408S
Discontinued
For upgrade or replacement options: Contact Us
SmartAVI FXCS-MX0408S is a Fiber Optic Singlemode 4 PC x 8 Users Matrix Switch. FXCS-MX0408 System Includes: (FXCS-MX0408, SM-CSW, and CCPWR06)
SmartAVI FXCore-AV Series Specifications and Information: FXCore-AV
SmartAVI FXCS-MX0408S Specifications:
| Optical | |
| Input Connector | Full Duplex multimode LC (Connecting to TX and RX units requires LC to LC connectors.) |
| Type | singlemode/multimode full duplex LC fiber optic inputs and outputs |
| Wavelength | 850nm, VCSEL Class 1 AEL Laser |
| Operating Distance | Up to 3,000 feet in Multimode Up to 15 miles in Singlemode |
| Compliance | FC-PI 200-M5-SN-I and 200-M6-SN-I 2.125 GBd, FC-PI 100-M5-SN-I, FC-PI 100-M6-SN-I, FC-PH2 100-M5-SN and FC-PH2 100-M6-SN-I 1.0625 GBd |
| Receiver Sensitivity | -21 dB Max |
| TX Output | Optical Power (Average) -10dBm |
| RX Input | Optical modulation amplitude (min) -17dBm |
| Channel Routing | 8x8 Non blocking |
| Control | RS-232 9600bps |
| Front Panel | LCD 2x20 |
| Other | |
| Power | 110V/220V internal power supply 40W |
| Video | Format: DVI-D Single Line Maximum Pixel Clock: 165 MHz Resolution: Up to 1920 x 1200 @60Hz |
| Audio | Signal Type - Stereo Audio Bandwidth - 15MHz, 0dB Impedance - 10K Ohm |
| RS-232 | Speed: Up to 115 Kbps |
| Environmental | Operating Temp.: 0-55 °C (32-131°F) Storage Temp.: -20-85 °C (-4-185 °F) Humidity: Up to 95% |
| Dimensions | 17" (43 cm) x 10.6" (26.9cm) x 1.75" (4.5cm) |
