Rose Vista L-series 4-Port KVM Switch

Rose Vista L-series 4-port KVM switch with DB25 connectors. Includes two 5' and two 10' cables and rack mount.

Rose Vista L-series Switch Kit Features and Benefits

• Low cost
• Chassis size: 13" wide, rack mountable 4-port, expandable to 64 computers
• Two 5' and two 10' cables included
• Connectors available in two styles:
  • DB25 connectors, uses Rose UltraCable, supports USB
  • PC connectors, uses native connectors for keyboard, video, and mouse
• Works with all PCs and most UNIX workstations
• USB support on DB25 models (with UltraCables)
• Supports wheel and serial mice
• Select computer from front panel or from easy to use keyboard commands
• Front panel LEDs show computer selected, power status, and activity
• Powered by your computer, no external power supply required
• Scan mode sequences through computers at adjustable rate
• Non-volatile memory stores configuration settings
• Rack mountable (rack mounts included)
• Made in USA

The Rose Vista Advantage

The Rose Vista L-series models are primarily intended for server racks. They can be rack mounted, and are 1U high. They have high resolution video and are available in PC and multi-platform versions. The multi-platform version supports the Apple ADB interface and is available in DB25 only. Each port is programmable as PC or Apple.

Keyboard and Mouse: All Vista models support full emulation of keyboard and mouse. It works with major operating systems such as Windows, Linux, and UNIX running on workstations such as SGI, IBM RS/6000, HP 9000, Dec Alpha, and others. All models support PS/2, PS/2 wheel, or serial mice. This model does not support a physical serial mouse. When using the DB25 models with USB cables, you can use PC-USB, Apple-USB, or Sun-USB.

Video: All Vista models have very high resolution capability and support VGA video beyond 1600 x 1280 non-interlaced. Keyboard, mouse, and video signals can be driven up to 1000 feet using our CrystalView extenders.
