16-Port Serial Console - Dual Power/LAN - LUC Port
SN0116A
Save $493.65
The SN9108 serial console server integrates cutting edge technologies to provide secure serial device access and management for data centers. This 8-port serial console server offers both in-band and out-of-band remote serial console access to servers and network devices via a direct Telnet/SSH client and applet viewer. SN serial console servers work in tandem with ATEN's Power Over the NET remote power management systems. Both can be utilized through ATEN's CC2000 software to provide centralized serial device access and integrated power management. With their comprehensive features, the SN Series helps to maximize IT productivity, increase scalability and reduce operational costs with easy remote management of serial devices.
Product Features and Benefits
- In-band Ethernet access of serial devices
- Browser access with an intuitive GUI
- Serial operating modes - Real COM, TCP Server, TCP Client, UDP, Serial Tunnel and Virtual Modem
- 128-/256-bit SSL encryption for Real COM, TCP Server, TCP Client, Serial Tunnel and Virtual Modem
- System configuration via web browser, Telnet/SSH client and local console
- Comprehensive logging and event notification
- Firmware upgradeable
- SSH and SSL support
- Supports CA certificates
- Configurable user permissions for port access
Package Contains
- 1x SN0116A Serial Console Server
- 2x Serial Adapters (1 x SA0141; 1 x SA0142)
- 1x Laptop USB Console Cable
- 2x Power Cords (AC model)
- 1x Mounting Kit
- 2x Lok-U-Plugs
- 1x Lok-U-Plug Installation Tool
- 1x Foot Pad Set (4 pcs.)
- 1x Software CD
- 1x User Instructions
| Serial Connections | 16 |
| Connectors | |
| Serial | 16 x RJ-45 Female |
| LAN | 2 x RJ-45 Female |
| Power | 2 x 3-prong AC socket |
| PON | 1 x RJ-45 Female |
| Modem | 1 x RJ-45 Female |
| USB | 3 x USB Type A Female |
| Laptop USB Console | 1 x Mini USB |
| Local Console | 1 x RJ-45 Female |
| Switches | |
| Reset | 1 x Recessed Pushbutton |
| Power | 2 x Rocker Switch |
| LED's | |
| Serial Port Status | 16(Green) |
| 10 / 100 / 1000 Mbps | 2(Red / Orange / Green) |
| Power | 2(Blue) |
| Power Consumption | 110V/22.9W; 220V/22.6W |
| Environment | |
| Operating Temperature | 32-122°F (0-50°C) |
| Storage Temperature | -4-140°F (-20-60°C) |
| Humidity | 0-80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 9.6 lbs. (4.35 kg) |
| Dimensions(L x W x H) | 17.2 x 13 x 1.7 in. (43.72 x 32.98 x 4.40 cm.) |
UPC 672792403361
EAN 0672792403361
