TLX video extender pair; single display up to 4096x2160 @30Hz with analog audio and serial RS-232

**Note: This is Transmitter/Reciever Pair. Click here for the Transmitter, or Click here for the Reciever.

TLX extension systems deliver uncompressed, high resolution video, audio and peripheral data on a single stream over single duplex fiber or single CATx cable. Configurable to specifically suit the requirements of any application, these TLX extender can support up to 4K @ 30Hz video (4096x2160) with full duplex stereo audio and serial (RS- 232). The TLX design offers support for both HDMI 1.4 and DisplayPort 1.2 connector types in a single extender, with full support for HDCP content. Additionally, TLX extension systems support embedded audio, with the ability to de-embed audio at the receiver.

Features & Benefits

• Connector supports both HDMI 1.4 and DisplayPort 1.2 cables
• 10Gbps bandwidth per port
• Multi-mode fiber
• Single mode fiber and CATx configurations available
• Extension of up to 80km over fiber
• Support for a single display up to 4096x2160 @ 30Hz - over a single fiber
• Supports HDCP content
• Local output port(s)
• Ethernet port for configuration, management and updates
• Support for embedded audio, with ability to de-embed at the receiver
• Support for unbalanced analog audio and serial RS-232
• Modular, hot-swappable form factor for field configuration
• Several chassis types available, for surface mount and rack mount applications
• Modular Chassis 1 - supports up to a single video extender module
• Modular Chassis 2 - supports up to two video extender modules
• Modular Chassis 4 - supports up to four video extender modules and offers redundant, hot-swappable power supplies

TLX KVM Extension Systems found here

Specifications
