4-Port 4K 60Hz 4:4:4 HDMI Splitter/Extender with 4 CAT5e/6 Receivers

VOPEX-C64K18GB-4

$845.00$777.01
Save $67.99

Discontinued
For upgrade or replacement options: Contact Us

The NTI VOPEX-C64K18GB-4 4K HDMI Splitter/Extender simultaneously distributes uncompressed Ultra-HD 4Kx2K 60Hz 4:4:4 HDMI video, multi-channel audio, and IR from one video source to up to four displays and speakers, each located up to 100 feet away via CATx cable.

The VOPEX-C64K18GB-4 system consists of two components: the 4K HDMI HDBase-T broadcast unit, which connects to the HDMI source and also supplies video to a local display; and a receiver (included) for each remote 4K HDMI display. The units are interconnected by CAT5e/6/6a/7 cable.

Also known as: HDMI Splitter, 4Kx2K Splitter/Extender, 4-way UHD distribution amplifier, 18Gb HDMI hub, extend Ultra-HD 4Kx2K 60Hz 4:4:4 to numerous displays

  • Transmits an uncompressed HDMI signal over one CATx cable to multiple display locations.
    • Extend Ultra-HD 4Kx2K 60Hz 4:4:4 to 100 feet.
    • Extend 4Kx2K 30Hz to 165 feet.
    • Extend 1080p to 200 feet.
    • Refer to the resolution chart in the specifications section for resolutions using different CATx cable types and lengths.
  • Supports Ultra-HD 4Kx2K resolutions (4096x2160 and 3840x2160 @24/25/30/60Hz YUV 4:4:4) and HDTV resolutions to 1080p.
  • HDMI features supported:
    • HDMI 2.0
    • YUV 4:4:4
    • Dolby TrueHD, DTS-HD Master Audio, Dolby Digital, DTS 7.1 and LPCM.
    • HDR
    • 3D
    • Bandwidth up to 600 Mhz (18 Gbps)
    • Support for CEC (consumer electronic control) compatible devices.
    • Lip Sync
  • HDCP 2.2 compliant.
  • Supports the DDC2B protocol.
  • Built-in default EDID table.
  • Ideal for digital signage, tradeshows, or classrooms where high quality video on multiple displays is needed.
NTI VOPEX-C64K18GB-4 Cat5 HDMI Splitter Extender Application Diagram

VOPEX-C64K18GB-4 Package Contents

NTI VOPEX-C64K18GB-4 Cat5 Receivers Package Contents

  • (1) Local Transmitter
  • (4) Remote Receivers
  • (1) IR Blaster
  • (4) IR Receivers
  • (1) Mounting Brackets for Transmitter and Receivers
  • (1) Power Adapter
  • (1) 2-Year Standard Warranty

VOPEX-C64K18GB-4 Resources

NTI VOPEX-C64K18GB-4 Manual NTI VOPEX-C64K18GB-4 Brochure (PDF)

NTI VOPEX-C64K18GB-4 Specifications

Dimensions (H x W x D)
  • Local unit: 1.22 x 8.37 x 4.00 in (31 x 212.6 x 101.5 mm)
  • Remote unit: 0.81 x 3.21 x 3.98 in (20.6 x 81.6 x 101 mm)
Local Unit (Transmitter)
  • Compatible with computers and UHD video sources (satellite receivers, Blu-Ray players, etc) with HDMI video.
  • Supports HDCP 2.2
  • Video bandwidth: 18 Gbps
  • One female HDMI connector for video source.
  • One female HDMI connector for local display.
    • Supports Ultra-HD 4Kx2K resolutions to 4096x2160 and HDTV resolutions to 1080p.
      • 4Kx2K (4096x2160 and 3840x2160) at 24/25/30/60Hz YUV 4:4:4.
  • One female 3.5mm port for IR transmitter.
    • IR frequency range: 20 to 60 kHz.
  • Four female RJ45 connectors for sending/receiving ultra-high definition video, audio, IR, and DDC signals.
  • Latency: 16mS
Remote Units (Receivers)
  • Supports Ultra-HD 4Kx2K resolutions to 4096x2160 and HDTV resolutions to 1080p.
    • 4Kx2K (4096x2160 and 3840x2160) at 24/25/30/60Hz YUV 4:4:4.
    • Refer to the resolution chart for resolutions using different CATx cable types and lengths.
  • One female HDMI connector for HDMI display.
    • Does not support DVI displays.
  • One female 3.5mm port for IR receiver (included).
    • IR frequency range: 20 to 60 kHz.
  • One female RJ45 HDBase-T connector for sending/receiving ultra-high definition video, audio, IR, DDC signals.
  • Supports embedded digital audio through HDMI compatible TVs or audio receivers.
Max Distance
  • 100 feet (30 meters) for Ultra-HD 4Kx2K 60Hz 4:4:4 over CATx cable.
  • 200 feet (61 meters) for 1080p over CATx cable.
Power
  • Local unit:
    • Input: 100 to 240 VAC at 50 or 60 Hz via AC adapter.
    • Output: 12VDC, 3A
  • Remote units: powered by local unit
Environmental
  • Operating temperature: 32°F to 140°F (0°C to 60°C).
  • Storage temperature: -4°F to 158°F (-20°C to 70°C).
  • Operating and storage relative humidity: 20% to 95% non-condensing RH.
Regulatory ApprovalCE, FCC, RoHS
Warranty2-Years
Cables
  • Use HD-xx-MM cable to connect an HDMI source or display.
    • Maximum HDMI cable length:
      • 50 feet for resolutions up to 4K @ 30Hz
      • 25 feet for resolutions up to 4K @ 60Hz
  • Use CATx solid or stranded straight through cable for TIA/EIA-568B wiring terminated with standard RJ45 connectors.
  • Cables not included.
CatX Cables
Distances and Resolutions for CAT5e/6/6a/7 Solid or Stranded Cables
CableDistanceMaximum Resolution
CAT5e UTP or STP50 feet
(15 meters)		4096x2160 and 3840x2160 at 60Hz YUV 4:4:4
165 feet
(50 meters)		4096x2160 and 3840x2160 at 30Hz YUV 4:4:4
200 feet
(61 meters)		1080p at 60Hz
CAT6 STP75 feet
(23 meters)		4096x2160 and 3840x2160 at 60Hz YUV 4:4:4
165 feet
(50 meters)		4096x2160 and 3840x2160 at 30Hz YUV 4:4:4
200 feet
(61 meters)		1080p at 60Hz
CAT6 UTP100 feetv(30 meters)4096x2160 and 3840x2160 at 60Hz YUV 4:4:4
165 feet
(50 meters)		4096x2160 and 3840x2160 at 30Hz YUV 4:4:4
200 feet
(61 meters)		1080p at 60Hz
CAT6a UTP100 feet
(30 meters)		4096x2160 and 3840x2160 at 60Hz YUV 4:4:4
165 feet
(50 meters)		4096x2160 and 3840x2160 at 30Hz YUV 4:4:4
200 feet
(61 meters)		1080p at 60Hz
CAT7 STP100 feet
(30 meters)		4096x2160 and 3840x2160 at 60Hz YUV 4:4:4
165 feet
(50 meters)		4096x2160 and 3840x2160 at 30Hz YUV 4:4:4
200 feet
(61 meters)		1080p at 60Hz
