17" Rack Mount Keyboard Drawer w/ High Brightness LCD & 16-Port PS/2 KVM Switch
HRKP117-1601
17" 1.5U Rackmount High Brightness LCD Monitor w/16-Port KVM, including (16) 6' cables
HRKP series is a combination of keyboard, mouse and high brightness monitor with KVM switch into a drawer, with features such as flip-up design, adjustable brackets, and built-in LCD OSD to provide effective assistance for an administrator to control multiple PCs.
HRKP series is cost effective for your limited IT budget over using CRT and rack mounting. Also, it is space saving for your compact environment rack.
AH HRKP117-1601 Features
- 1.5U 17" LCD screen
- Rear rackmount bracket included.
- Standard D-sub 15-pin VGA input connector.
- Provides the longest lamp life possible for all brightness levels.
- Power saving feature for prolonging the life of LCD panel
- High brightness and contrast enhances display panel
- Unique mechanical design to maximize rack mountable space.
- Slide rails have fixed position to prevent movement of keyboard.
- Lightweight aluminium construction - with a black anodize finish.
- Built in On Screen Display controlled by integral membrane switches.
- Brightness more than 1000cd/m2
- Adjustable mounting brackets from 390mm to 790mm (front to rear 19" mounts)
AH HRKP117-1601 Specifications
| LCD | ||
| Panel | Samsung 17" LCD Panel | |
| Screen Type | TFT | |
| Display Area | 337.92(H) x 270.34(V) mm | |
| Contrast Ratio | 420 : 1 | |
| Viewing Angle | 120 ° (H) x 100 ° (V) (Typ.) | |
| Resolution | 1280 x 1024 | |
| Pixel pitch | 0.264(H) x 0.264(W) mm | |
| Response Time | Tr=5ms, Tf=20ms (Typ.) | |
| Brightness | 1000 cd/m2 | |
| Panel Color | 16.7M | |
| Back Light | 4 CCFTs (Cold Cathode Fluorescent tube) | |
| Video | ||
| Horizontal Synchronization | 64 - 80 KHz (Typ.) | |
| Vertical Synchronization | 60-75 Hz (Typ.) | |
| Input Signal | Analog RGB 0.7Vp-p | |
| Power Management | VESA DPMS | |
| Control | ||
| OSD Control | Brightness, Contrast, Colour, Clock, H.Position, V.Position, Phase, Scaling, Auto config, Input select, Multi window, Clear EEPROM, OSD adjust, Save | |
| External Connection | ||
| Power Input | 12V/5A DC adapter | |
| Video Input | 15-pin D-Sub connector | |
| Product dimension | 43.9(W) x 6.6(H) x 60(D)cm | |
| Packing dimension | 73.5(L) x 57.5(W) x 18(H)cm | |
| Net / gross weight | 30.86 lb / 50.71 lb 14 kg / 23 kg |
