2-Port ACS800 Serial Console - US Power Cord
ACS802EAC-001
Discontinued
Replaced by: Avocent ACS804MEAC-400
Alternative options: Contact Us
| US Power Model | PDU Power (C13) Model | Ports | Power Source | Built-in Modem |
|---|---|---|---|---|
| ACS802EAC-001 | ACS802EAC-400 | 2 | Single AC | -- |
| ACS802MEAC-001 | ACS802MEAC-400 | 2 | Single AC |  |
| ACS804EAC-001 | ACS804EAC-400 | 4 | Single AC | -- |
| ACS804MEAC-001 | ACS804MEAC-400 | 4 | Single AC | |
| ACS808EAC-001 | ACS808EAC-400 | 8 | Single AC | -- |
| ACS808MEAC-001 | ACS808MEAC-400 | 8 | Single AC | |
The Avocent ACS802EAC-001 2-port serial console system with US power cord takes our renowned enterprise class technologies utilized in data centers around the world and packages the key features into an exciting compact and cost effective form factor. Providing serial access, environmental monitoring, IoT integration and remote networking capability to the Edge oriented market sectors of financial institutions, retail chains, education and others.
Regional IT managers and facility engineers will benefit with the ability to perform secure, remote management and out-of-band management of IT assets from anywhere in the world. Featuring a dual-core ARM processor architecture with expanded memory capabilities, RS232/RS485/RS422 serial access, USB, Gigabit Ethernet and environmental sensor access, the Yochto project based Linux operating system and available DSView management software, provides the Avocent ACS 800 optimal performance, security, reliability for a complete out-of-band management solution.
Features & Benefits
- Secure in-band and out-of-band network remote management
- Fast, automated configuration with Zero Touch Provisioning
- Access and troubleshoot remote locations using automatic network failover to cellular (and failback)
- Compliance with data center access and security policies - customizable, multiple access levels
- No need for adaptors with automatic Cyclades and Cisco pin-out conversions
- Expanded support for Rack PDUs from Vertiv, ServerTech, APC, Raritan and Eaton
- Support for Emerson GXT4 UPS system
- IPv6 and IPv4 support for new network deployments
- Support for Avocent DSView management software
- Console event logging and notification, including "last gasp" capture
- 4 USB ports to support new IT equipment and external devices
- Includes Environmental sensor port to connect temperature, humidity, differential pressure, leak, door pin sensors (up to 8 can be daisy chained)
- Extensive Regulatory & Security compliance with easy troubleshooting
Operating System
- Yochto project based Linux
Applications
- Zero Touch Provisioning (ZTP)
- In-band (Ethernet) and out-of-band (dial-up/cellullar modem) support
- Optional external 4G/LTE celluar router
Availability
- Automatic Ethernet or Cellular failover using second GbE port for failover
- Support for multiple-routing tables
- External AC/DC power supply design
- Dual GbE Ethernet support
- 4x USB port support
Security
- Preset security profiles - secure, moderate and open
- Custom security profiles
- IPSec support with Third-Party certificates
- X.509 SSH certificate support
- SSHv1 and SSHv2
- Local, RADIUS, TACACS+, LDAP/AD, NIS and Kerberos authentication
- Two-factor authentication (RSA SecurID)
- One-Time Password (OTP) authentication
- Local, backup-user authentication support
- PAP/CHAP and Extensible Auhtentication Protocol (EAP) authentication (for dial-up lines)
- Group authorization:
- TACACS+, RADIUS and LDAP
- Port access
- Power access
- Appliance privilege
- IP packet and security filtering
- User-access lists per port
- System event syslog
- IPSec with NAT traversal support
- IP forwarding support
- Secure factory defaults
- Strong password enforcement
Console Management
- Sun break-safe (Solaris Ready Certified)
- Break-over SSH support
- Off-line data buffering - local and remote (NFS/Syslog/DSView software)
- Level-based syslog filters
- Time stamp and rotations for data buffering
- Unlimited number of simultaneous sessions
- Simultaneous access on the same port (port sniffing) with ability to toggle
- Configurable event notification (e-mail, pager, SNMP trap)
- Customizable, global time zone support
- Multiple and customizable user levels of access
Port Access
- Directly by server name or device name
- CLI Command
- Simultaneous Telnet and SSH access
- HTTP/HTTPS
System Management
- Configuration wizard in Web for first-time users
- Auto-discovery for automatic deployment
- Command line interface (CLI)
- Web Management Interface (HTTP/HTTPS)
- SNMP
- Internal temperature sensor
Cabling
- CAT-5 compatible adapters for simpler cabling
- Autosensing for Cyclades and Cisco pin-outs for serial ports
Upgrades
- Upgrades available on FTP site, no charge
- TFTP support for network boot
ACS802EAC-001 Package Contents
ACS802EAC Resources
Avocent ACS802EAC Datasheet (PDF)
Avocent ACS802EAC Manual / User Guide (PDF)
Guides & Installation
Avocent ACS802EAC Rack Mounting Guide (PDF)
Avocent ACS 800 Command Reference Guide (PDF)
Avocent ACS 800 API Guide (PDF)
Borchures
Avocent / Libert IT Products Catalog (PDF)
ACS 802EAC Accessories
| Adapters | Desciption |
|---|---|
| ADB0017 | RJ45 to DB25F cross converter |
| ADB0025 | RJ45 to DB25M cross converter |
| ADB0036 | RJ45 to DB9F cross converter |
| ADB0037 | RJ45 to DB9M cross converter |
| ADB0039 | RJ45 to RJ45 Sun/Cisco cross converter |
| ADB0040 | RJ45 to RJ45 Rackable converter |
| ADB0210 | RJ45 to DB9F s/t converter |
| Cables | Desciption |
| CAB0017 | RJ-45M to DB-25F crossover cable (6 ft.) |
| CAB0018 | RJ-45M to RJ-45M straight-through CAT-5 cable (7 ft.) |
| CAB0025 | RJ-45M to DB-25M straight-through cable (6 ft.) |
| CAB0036 | RJ-45M to DB-9F crossover cable (6 ft.) |
| CAB0045 | RJ-45M to RJ-45M Sun/Cisco crossover cable (10 ft.) |
| CAB0046 | RJ-45M to DB-25M crossover cable (6 ft.) |
| CAB0286 | DB-9F to DB-9F crossover cable (6 ft.) |
| Rackmounting Kits | Desciption |
| RMK-91 | 1U Rack Mount Tray for ACS800 |
| RMK-92 | DIN-Rail Mount Kit for ACS800 |
| RMK-93 | Wall Mount Kit for ACS800 |
ACS802EAC-001 Technical Specifications
| Mechanical | |
|---|---|
| Height | 1.3 in. (3.302 cm) |
| Width | 8.38 in. (21.2852 cm) |
| Depth | 7.16 in. (18.1864 cm) |
| Weight | 3.8 lb. (1.72365 kg) |
| Environmental | |
| Operating Temperature | -4° to 158°F (-20° to 70°C) |
| Storage Temperature | -4° to 158°F (-20° to 70°C) |
| Humidity | 20% to 80% relative humidity (non-condensing) across the operating temperature range |
| Power | External AC/DC Power Adapter (power brick) 100-240 VAC, 50/60 Hz Input, 12 VDC Output |
| Operating Voltage | 100-240 VAC, 50/60 Hz |
| Power Usage | Nominal voltage 120VAC:
|
| Hardware Specifications | |
| CPU | Dual Core ARM Cortex-A9 @ 766MHz |
| Memory | 1GB DDR3L RAM 16GB eMMC Flash |
| Interfaces | 2 dual media 1000Base-TX Copper ports Up to 8 serial ports with autosensing and switching support of Avocent andCisco pinouts All serial source ports support RS232/422/485 multi-protocol with autosensing and switching support of Avocent and Cisco pinouts in RS232 mode 1 serial console port 4 USB 2.0 host ports 1 V.92/56K analog MODEM port 1-Wire interface for external sensors Single RJ45 connector with four digital-in or digital-out ports for external contact closure sensors |
| Standards | |
| Approved Agency | Emissions and Immunity: Safety: |
