Aluminum 19" LCD LED Display with NEMA 4 / IP65 Protection
NAP-19
Save $89.00
Aspect Ratio: 4:3
Monitor Types:
Standard Aluminum
Front Bezel
NEMA 4 / IP65
Protection
Aluminum
Front Cover
Universal
Open Frame
| Model | Aspect Ratio | Screen Size | Brochure |
|---|---|---|---|
Standard Aluminum Front Bezel | |||
| AP-K55 | 16:9 (4K / 1080p) | 55" |  |
| AP-K43 | 43" | | |
| AP-K32 | 32" | | |
| AP-K23 | 23" | | |
| AP-K17 | 17" | | |
| AP-K15 | 15" | | |
| AP-F21 | 16:9 (1080p) | 21" | |
| AP-F17 | 17" | | |
| AP-F15 | 15" | | |
| AP-X24 | 16:10 (1920x1200) | 24" | |
| AP-X17 | 17" | | |
| AP-W19 | 16:10 (1440x900) | 19" | |
| AP-20 | 4:3 (1600x1200) | 20" | |
| AP-19 | 4:3 (1280x1024) | 19" | |
| AP-17 | 17" | | |
| AP-15 | 4:3 (1024x768) | 15" | |
| AP-12 | 4:3 (800x600) | 12" | |
| AP-10 | 10" | | |
| AP-8 | 8" | | |
| AP-6 | 4:3 (640x480) | 6.5" | |
Standrd Aluminum Front Bezel with | |||
| NAP-K55 | 16:9 (4K / 1080p) | 55" | |
| NAP-K43 | 43" | | |
| NAP-K32 | 32" | | |
| NAP-K23 | 23" | | |
| NAP-K17 | 17" | | |
| NAP-K15 | 17" | | |
| NAP-F21 | 16:9 (1080p) | 21" | |
| NAP-F17 | 17" | | |
| NAP-F15 | 15" | | |
| NAP-X24 | 16:10 (1920x1200) | 24" | |
| NAP-X17 | 17" | | |
| NAP-W19 | 16:10 (1440x900) | 19" | |
| NAP-20 | 4:3 (1600x1200) | 20" | |
| NAP-19 | 4:3 (1280x1024) | 19" | |
| NAP-17 | 17" | | |
| NAP-15 | 4:3 (1024x768) | 15" | |
| NAP-12 | 4:3 (800x600) | 12" | |
| NAP-10 | 10" | | |
| NAP-8 | 8" | | |
| NAP-6 | 4:3 (640x480) | 6.5" | |
Aluminum Front Cover | |||
| DP-K55 | 16:9 (4K / 1080p) | 55" | |
| DP-K43 | 43" | | |
| DP-K32 | 32" | | |
| DP-K23 | 23" | | |
| DP-K17 | 17" | | |
| DP-K15 | 17" | | |
| DP-F21 | 16:9 (1080p) | 21" | |
| DP-F17 | 17" | | |
| DP-F15 | 15" | | |
| DP-X24 | 16:10 (1920x1200) | 24" | |
| DP-X17 | 17" | | |
| DP-W19 | 16:10 (1440x900) | 19" | |
Universal Open Frame | |||
| DP-K55 | 16:9 (4K / 1080p) | 55" | |
| OP-K43 | 43" | | |
| OP-K32 | 32" | | |
| OP-K23 | 23" | | |
| OP-K17 | 17" | | |
| OP-K15 | 17" | | |
| OP-F21 | 16:9 (1080p) | 21" | |
| OP-F17 | 17" | | |
| OP-F15 | 15" | | |
| OP-X24 | 16:10 (1920x1200) | 24" | |
| OP-X17 | 17" | | |
| OP-W19 | 16:10 (1440x900) | 19" | |
Aspect Ratio: 4:3
Screen Size: 19 in
Model: NEMA4 / IP65 Protection
Display Features & Benefits
- 19" LCD with resolution 1280 x 1024
- Panel-mount, VESA mount
- Green LED-backlit panel technology
- 6mm (.24 in) aluminum front bezel with protective glass & water proof sealed gasket
- Rugged construction against external impact
- Protective 3mm glass
- Standard with DVI-D, VGA
NAP-19 Resources & Downloads
NAP-19 Datasheet (PDF)
NAP-19 Manual (PDF)
UltraView NAP-19 Specifications
| Mechanical | |
| Height | 15.1 in. (38.4 cm.) |
| Width | 18.8 in. (47.7 cm.) |
| Depth | 2.5 in. (6.4 cm.) |
| Weight | 16.9 lbs. (7.7 kg.) |
| Package Dimensions (HxDxW) | 25.6 x 4.9 x 23.5 inch (651 x 124 x 597 mm) |
| Package Weight | 23.1 lbs. (10.5 kg.) |
| Environmental | |
| Operating Temperature | 0 to 55°C Degree |
| Storage Temperature | -5 to 60°C Degree |
| Relative Humidity | 5~90%, non-condensing |
| Shock | 10G acceleration (11ms duration) |
| Vibration | 5~500Hz 1G RMS random vibration |
| Power | Auto-sensing 100 to 240VAC, 50 / 60Hz |
| LCD Panel | |
| Display Size | 19" TFT |
| Resolution | 1280 x 1024 |
| Brightness (cd/m2) | 250 |
| Colors | 16.7 M |
| Contrast Ratio (typ) | 1000:1 |
| Viewing angle (H/V) | 170° x 160° |
| Active area (mm) | 376 x 301 |
| Signal Input | VGA, DVI-D |
