ADDERView PRO Multi-Screen DVI-I USB KVM (Three Monitor)
AV4PRO-DVI-TRIPLE-US
Save $153.50
Video Input: Dual Link DVI-I (DVI or VGA w/ adapter)
Video Output: Triple Monitor
The AdderView Pro AV4PRO-DVI-TRI-US is a professional grade triple screen KVM switch delivering ultimate flexibility for users who wish to share a high resolution screen and modern USB peripherals between a multiplicity of computers.
The AdderView Multiscreen AV4PRO-DVI-TRI is designed to enable four triple-head computers to be controlled from a single high resolution KVM console three either dual link DVI or high definition analogue video links. The switch makes use of Adder's True Emulation technology which enables USB HID devices to be continuously emulated to each computer. This unique technology enables instantaneous and reliable hotkey switching whilst also supporting the extra keys and features of enhanced keyboards and mice. Furthermore, the AdderView includes two independently switchable USB 2.0 channels and an audio channel, giving the user the flexibility to attach selected peripherals to different computers. Models are available supporting single, dual, triple or quad head DVI or VGA computers.
Adder AV4PRO-DVI-TRI Layout
Adder AV4PRO-DVI-TRI Features
True USB 2.0 emulation
Unlike most KVM switches, which only support the most basic keyboard and mouse features, Adder's revolutionary 'True Emulation' allows you to use the extra function keys, wheels, buttons and controls that are commonly found on modern keyboards and mice. You can also use any other USB interface device including graphics tablets, jog shuttles, joysticks, 3D explorers, and wireless bluetooth keyboard & mouse*.
Independent USB & Audio device switching
The AdderView Pro AV4PRO-DVI-TRI includes two independently switchable USB 2.0 channels and an audio channel, giving the user the flexibility to attach selected peripherals to different computers. For example, use the KVMA console to work on one computer whilst your USB peripherals are connected to other computers and your speakers are playing music from yet another.
Broad High Speed device support - Transparent USB 2.0 Hub
An integrated transparent 2-port USB 2.0 hub allows a vast range of USB devices can be connected to the AV4PRO-DVI-TRI from non standard keyboard / mouse devices to flash drives, printers and scanners.
Fast & Reliable Switching
Country code reporting, extended DDC EDID profile and continuous keyboard and mouse emulation ensure faultless operation. The USB 2.0 switching action has also been carefully engineered to ensure maximum computer reliability when connecting and disconnecting USB devices.
Channel selection options
The AdderView Pro AV4PRO-DVI-TRI can be switched using the front panel buttons, selectable keyboard hotkeys, 3 button mice, an On-Screen-Display (OSD), or using simple ASCII codes via serial RS232. Optionally, you can also use the RC4 remote switch to make your selection. These switching options allow you to rapidly reassign connected devices to any of the connected computers.
Multi-platform support
The AV4PRO-DVI-TRI works with all known software and computer platforms, with PS/2, USB and Sun, including Windows (all), DOS, Linux, Unix, BSD, all Sun OS, all Mac OS, NetWare, etc.
Plug and Play
AdderView Pro KVM devices are delivered in a zero configuration state so you can plug them in and start working on them straight away. There is no need for drivers or software to be installed.
Serial RS232 port for control, synchronization and upgrade
- Remotely switch AV4PRO-DVI-TRI using simple ASCII codes
- Integration with RS232 controlled power switches to provide a complete hard reboot function
- Flash upgrade
Expand up to a 7-monitor KVM Switch
AV4PRO-DVI-TRI can be linked with another Adder AV4PRO unit to create up to a 4-port quad-monitor, 5-monitor, 6-monitor, or 7-monitor KVM Switching system, by using a VSC41 synchronisation cable.
AV4PRO-DVI-TRI-US Package Contents
- (1) AV4PRO-DVI-TRI KVM Switch
- (1) Power adapter (20W) and US-specific power lead
- (1) Information wallet containing: Quick start guide and Safety document
- (4) Self-adhesive rubber feet
- (1) 2-Year Limited Warranty & Lifetime World Class Support
AV4PRO-DVI-TRI Resources
Adder AV4PRO-DVI-TRI Datasheet (PDF)
Adder AV4PRO-DVI-TRI Manual (PDF)
Adder AV4PRO-DVI-TRI-US Specifications
| Mechanical | |
| Physical | 2.5U High metal case |
| Width | 10.24 in. (26 cm.) |
| Height | 3.93 in. (10 cm.) |
| Depth | 5.91 in. (15 cm.) |
| Compatibility | |
| Hardware Compatibility | All computers with USB interfaces |
| Software Compatibility | Operates with all known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, all Sun OS, all Mac OS, NetWare etc. Computer connections at switch: USB2.0 type B, Dual-link DVI-I (up to 4 per connection), 3.5mm stereo jack |
| Computer Connections at Switch | USB 2.0 type B, Dual link DVI-I, 3.5mm stereo jack |
| Local KVM Console Connection Video | 3x Dual-link DVI-D (Triple Monitor) |
| Keyboard/Mouse | 2 x USB Type A |
| Switched USB | 2 x USB2.0 Type A |
| Audio | 3.5mm stereo jack |
| Other connections | Options (flash upgrade, sync with other AV4PRO-DVI-MS and RS232 triggered power switches): Modular 10P10C |
| Power | 2.5mm DC jack (power adapter included), 100-240VAC 50/60Hz input to power adapter, 5VDC 2A output from power adapter |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Approvals | CE, FCC |
This part is also known as AV4PRO-DVI-TRI-US, AV4PRO-VGA-TRIPLE, and AV4PRO-VGA-TRIPLE-US.
Question: Do you have a switch for 2 PC's sharing 3 monitors, that supports 2 MP? I know the Adder AV4PRO-DVI-TRI-US will (up to 4 MP), but do you also have a less expensive switch that supports 2 MP monitors? Thanks.
Answer: Thank you for your inquiry. Adder also makes a VGA version (https://www.kvm-switches-online.com/av4pro-vga-triple.html), which will support 2MP resolutions including 1600 x 1200.
To discuss other potential solutions, please contact your KVM Switches Online representative by calling 1-877-586-6654 or via our online chat to discuss your project in greater detail.
Question: When will you have this model with USB 3.0 instead of USB 2.0? Also will there be a triple HDMI version with USB 3.0 soon?
Answer: Thank you for your inquiry. Unfortunately, while support for USB 3.0 my be under development for the ADDERView Pro series, we do not believe it will be released anytime in the near future.
We are also unaware of any plans to release a triple-head HDMI ADDERView Pro KVM, but we will absolutely pass along your interest to Adder.
Question: does this work if the video card (quadro k2000) has display port outputs and I use a display port to dvi adapter at the video card end before connecting the dvi cable between the adapter and kvm?
Answer: Thank you for your inquiry,
Adapting your DisplayPort outputs to DVI should be fully compatible with the Adder AV4PRO-DVI-TRI KVM Switch.
Question: Is there any difference between this unit and the Rose multi video dvi unit? They look the same externally. Thx
Answer: Thank you for your inquiry,
Both units appear to be the same based on the casing and features. That being said, internally / functionally the two units may be different even if the units may have come from the same manufacturer.
Question: Is this available in 2 Port? For switching between 2 Triple-head computers.
Answer: Thank you for your inquiry,
The Adder AV4PRO-DVI-TRIPLE is only available as a 4-Port model, but you can always simply plug in two sources, and leave the other two open ports for future expansion.
I am also currently not aware of another similar DVI-based Triple-monitor KVM switch that would be below 4-ports.
Please let us know if there is anything else we can help you with!
