1U 17" Rack Mount Monitor Drawer with SUN Keyboard & Samsung TFT LCD Monitor

S117

$1,194.00
Model: Standard
Screen Size: 17"
FREE Shipping on orders over $100

The S117 is a 1U 17" Rackmount LCD with 104-keys keyboard featuring standard SUN hot keys.  This rack mount monitor features a 1U slim design, adjustable brackets, built in LCD OSD to provide effective assistance for an administrator to control PC system.

Austin Hughes CyberView S117 Diagram

S117 Features:

  • 1U 17" LCD console drawer
  • Direct support for SUN Micro 1152x900 native resolution
  • Secure remote user access across the world wide web
  • 104-key keyboard with SUN hotkey
  • Short depth design of 460mm ( 18.1" )
  • New enhanced aesthetics with molded front handle
  • Front USB port for device access (USB Hub KVM only)
  • 2 post rack mounting available
S117 SUN keyboard Options

Optional Configurations (Contact us for availability)

  • Front USB hub port for device access
  • DC Power: 12, 24, 48, 125 V DC
  • Multiple Integrated KVM Switch options
  • 2-post rack mounting brackets ( ORB-2.1 )

S117 Package Contents

CyberView S117 Package Contents
  • (1) S117 Console Drawer
  • (1) CX-6 6ft DVI-D console cable (or optional CB-6 6ft VGA console cable )
  • (1) Power cord
  • (8) M6 screw, cage nut & cup washer
  • (1) 2-year standard warranty ( upgradable up to 5 years )

S117 Resources

CyberView S117 Diagram S117 Brochure (PDF)
S117 Manual (PDF)
S117 Integrated KVM Manuals (Link)

S117 Specifications

Mechanical
Product Dimensions (H x W x D)
Single Console1.73 x 17.4 x 18.1 in.
(44 x 442 x 460 mm.)
Console w/ KVM1.73 x 17.4 x 22.8 in.
(44 x 442 x 580 mm.)
Package Dimensions (H x W x D)
Single Console /
Console w/ KVM		5.5 x 23.2 x 31.8 in.
(140 x 590 x 808 mm.)
Net Weight
Single Console26.4 lbs. (12 kg)
Console w/ KVM28.6 lbs. (13 kg)
Gross Weight
Single Console36.5 lbs. (16.6 kg)
Console w/ KVM41.8 lbs. (19 kg)
Mounting Distance
Single Console18.5 ~ 27.6 in
(470 ~ 700 mm)
Console w/ KVM18.5 ~ 31.5 in
(470 ~ 800 mm)
Console Ports
Video InputVGA + DVI-D single link
KB / MS Combo ( USB or PS2 )
VGA console 6ft cable (CB-6)
--OR--
DVI-D console 6ft cable (CX-6)
Drawer end : DB-15 ( VGA + USB KB / MS )
Server end : VGA + USB type A
Drawer end : DVI-D + DB-15 ( USB KB / MS )
Server end : DVI-D + USB type A
LCD Screen
LCD panel size ( diagonal )17"
Backlight typeLED
Direct resolution1152 x 900
Native resolution1280 x 1024
Brightness (cd/m2)250
Colors16.7 M
Contrast Ratio (typ)1000 : 1
Viewing angle ( L/R/U/D ) 85/85/80/80
Viewing angle (H x V) 160° x 160°
Response time ( ms )5
Dot pitch ( mm )0.264
Display area ( mm )337.92H x 270.33V
Surface treatmentHaze 25%, Hard-coating
Surface hardness3H
MTBF (hrs)30,000
Audio Option
Speaker2x 2W (Dual Stereo)
Input Connector3.5mm stereo jack
Input Impedance / Power level 30Ω / 750mV
Output Connector3.5mm stereo jack
Output Impedance / Power level 30Ω / 2.8V
Power
Power InputAuto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption
(Single Console / with KVM)
Screen onMax. 25W / Max. 55W
Power saving modeMax. 4W / Max. 34W
Power button onMax. 1W / Nil
Environmental
Operating Temperature0 to 55°C Degree
Storage Temperature-20 to 60°C Degree
Operating Humidity20~90%, non-condensing
Relative Humidity5~90%, non-condensing
Operating Altitude16,000 ft
Non-operating Altitude40,000 ft
Shock 10G acceleration (11ms duration)
Vibration10~300Hz 0.5G RMS random vibration
Regulatory Compliance
EMCFCC, CE & CCC certified
Safetyc UL us, CE / LVD & CCC certified
EnvironmentRoHS2 & REACH compliant

S117 models with Integrated KVM Switch (Contact us for pricing / availability)

Austin Hughes CyberView S117 with Matrix CAT6 KVM
Matrix CAT6 KVM		Local UserExtendedIP8-Port16-Port32-Port
111-S117-MUIP1613S117-MUIP3213
121-S117-MUIP1614S117-MUIP3214
112-S117-MUIP1624S117-MUIP3224
110-S117-MU1602S117-MU3202
120-S117-MU1603S117-MU3203
130-S117-MU1604S117-MU3204

Austin Hughes CyberView S117 with Combo CAT6 KVM
CAT6 KVM		Local UserExtendedIP8-Port16-Port32-Port
101S117-UIP802S117-UIP1602S117-UIP3202
110S117-U802S117-U1602S117-U3202
100S117-U801S117-U1601S117-U3201

Austin Hughes CyberView S117 with DVI-D KVM
DVI-D KVM		Local UserExtendedIP12-Port
100S117-1201D

Austin Hughes CyberView S117 with Matrix VGA DB-15 KVM
Matrix VGA DB-15 KVM		Local UserExtendedIP8-Port16-Port32-Port
111S117-MIP813S117-MIP1613-
121S117-MIP814S117-MIP1614-
112S117-MIP824S117-MIP1624-
110S117-M802S117-M1602-
120S117-M803S117-M1603-
130S117-M804S117-M1604-

Austin Hughes CyberView S117 with VGA DB-15 KVM
VGA DB-15 KVM		Local UserExtendedIP8-Port16-Port32-Port
101S117-IP802S117-IP1602-
110S117-802S117-1602-
100S117-S801S117-S1601-

Austin Hughes CyberView S117 with USB HUb VGA DB-15 KVM
VGA DB-15 KVM with USB Hub		Local UserExtendedIP8-Port16-Port32-Port
101S117-IP802HS117-IP1602H-
110S117-802HS117-1602H-
100S117-801HS117-1601H-

Austin Hughes CyberView S117 with PS2 DB-15 KVM
VGA PS/2 KVM		Local UserExtendedIP8-Port16-Port32-Port
100S117-801S117-1601-
