2U 17" 4K Triple-display Rack Drawer
MRP-K17-3
Save $975.00
Model: MRP-K17-3
| Series | Model |
|---|---|
LCD Display Panel | |
Standard | |
| RP-K617 | 6U 17" 4K |
| RP-F617 | 6U 17" 1080p FHD |
| RP-X617 | 6U 17" 1920 x 1200 |
| RP-717 / RP-819 / RP-920 | 7U 17" / 8U 19" / 9U 20" |
| RP-W719 | 7U 19" 1440 x 900 |
Large | |
| RP-K923 | 9U 23" 4K |
| RP-F821 | 8U 21" 1080p FHD |
| RP-X924 | 9U 24" 1920 x 1200 |
High brightness | |
| RP-HF617 | 6U 17" 1080p FHD |
| RP-HF821 | 8U 21" 1080p FHD |
| RP-H717 / RP-H819 | 7U 17" / 8U 19" 1280 x 1024 |
| RP-HW719 | 7U 19" 1440 x 900 |
Sun display | |
| SP-717 / SP-819 / SP-920 | 7U 17" / 8U 19" / 9U 20" 1152 x 900 |
Split Quad display | |
| RP-F921QD-1080 | 9U 21" 1080p FHD |
| RP-919QD | 9U 19" 1280 x 1024 |
| RP-W819QD | 8U 19" 1440 x 900 |
Rack Monitor Drawer | |
Regular | |
| RP-K117 | 1U 17" 4K |
| RP-F117 | 1U 17" 1080p FHD |
| RP-X117 | 1U 17" 1920 x 1200 |
| RP-117 / RP-119 | 1U 17" / 1U 19" 1280 x 1024 |
| RP-W119 | 1U 19" 1440 x 900 |
| RP-120 | 1U 20" 1600 x 1200 |
Ultra Short depth | |
| RP-K1417 | 1U 17" 4K |
| RP-F1417 | 1U 17" 1080p FHD |
Dual & Triple display | |
| MRP-K17 | 2U 17" 4K |
| MRP-F17 | 2U 17" 1080p FHD |
| MRP-19 | 2U 19" 1280 x 1024 |
High brightness | |
| RP-HF117 | 1U 17" 1080p FHD |
| RP-HW119 | 1U 19" 1440 x 900 |
| RP-H117 / RP-H119 | 1U 17" / 1U 19" 1280 x 1024 |
Sun display | |
| SP-117 / SP-119 | 1U 17" / 1U 19" 1152 x 900 |
| SP-120 | 1U 20" |
Split Quad display | |
| RP-119QD | 1U 19" 1280 x 1024 |
| RP-W119QD | 1U 19" 1440 x 900 |
Version: 17" 4K UHD
Displays: Triple
The CyberView MRP-K17-3 is a 2U Triple-display (17") 4K UHD rack drawer that is designed for Command and Control Systems which demand quick deployment for multi-faceted displays.
4K 17" displays satisfy the increasing demand for superior graphics and image clarity. 2U 22" depth platform allows for small size and transit case portability. To ensure chassis ruggedness, mobility and quality, as well as being suitable for harsh environment applications, the MRP-K17-3 drawer is meticulously constructed by our team of experts in our own CNC facilities for such applications.
MRP-K17-3 Features and Benefits
- Display port 1.2 video input for 4K ( per display )
- 4K UHD (3840 x 2160) native resolution / 1920 x 1080 & 1920 x 1200 resolution support
- 2U 22" short depth design
- Light weight only 46 lbs / 21 kgs
- Rugged construction for mobility & durability
- Built-in solid bearing slide rails
- Built-in dual stereo speaker ( per display )
- Fits 24" ~ 36" rack via adjustable mounting brackets
- 2-year standard warranty ( upgradable up to 5 years )
MRP-K17-3 Options
- 3G / HD / SD-SDI Broadcast-grade input
- Sunlight readable 17" FHD display
- Audio Option: 2x 2W Speakers + aux input & output
- DC power : 12V / 24V / 48V / 125V / 250V
- Touchscreen : Projected Capacitive ( 10-pt ) / Resistive ( 1-pt )
MRP-K17-3 Package Contents
- (1) MRP-K17-3 Monitor Drawer
- (3) 6ft DisplayPort cable
- (1) Power adapter & cord
- (8) M6 screw, cage nut & cup washer
- (1) 2-year standard warranty ( upgradable up to 5 years )
MRP-K17-3 Resources
MRP-K17-3 Brochure (PDF)
MRP-K17-3 Manual (PDF)
CyberView MRP-K17-3 Specifications
| Mechanical | |||||||
| Product Dimensions (H x W x D) | 3.5 x 17.4 x 21.7 in ( 88 x 441.6 x 550 mm ) | ||||||
| Package Dimensions (H x W x D) | 7.8 x 22.8 x 26.9 in ( 197 x 580 x 683 mm ) | ||||||
| Net Weight | 53 lb ( 24.1 kg ) | ||||||
| Gross Weight | 64.5 lb ( 29.3 kg ) | ||||||
| Chassis Color | Dark | ||||||
| Chassis Materials | Steel | ||||||
| Mounting | |||||||
| Rack Mounting | 2U | ||||||
| Mounting Depth | 21.65 to 31.1 inch ( 550 to 790 mm ) | ||||||
| Console Ports | |||||||
| Video Input | DisplayPort 1.2 / HDCP 1.3 | ||||||
| Video Option | HDMI 2.0 / HDCP 2.2 | ||||||
| LCD Screen | |||||||
| LCD panel size ( diagonal ) | 17.3" | ||||||
| Backlight type | LED | ||||||
| Native resolution | 3840 x 2160 | ||||||
| Brightness (cd/m2) | 400 | ||||||
| Colors | 16.7 M, 8-bit | ||||||
| Contrast Ratio (typ) | 1000 : 1 | ||||||
| Viewing angle ( L/R/U/D ) | 89/89/89/89 | ||||||
| Response time ( ms ) | Max. 30 ms | ||||||
| Dot pitch ( mm ) | 0.0995 | ||||||
| Display area ( mm ) | 382.12H x 214.94V | ||||||
| Surface treatment | Anti-glare | ||||||
| Surface hardness | 3H | ||||||
| MTBF (hrs) | 20,000 | ||||||
| Audio Option | |||||||
| Speaker | Built-in 2x 2W dual stereo speaker ( per display ) | ||||||
| Power | |||||||
| Power Input | Auto-sensing 100 to 240VAC, 50 / 60Hz | ||||||
| Power Consumption |
| ||||||
| Environmental | |||||||
| Operating Temperature | 0 to 55°C Degree | ||||||
| Storage Temperature | -20 to 60°C Degree | ||||||
| Operating Humidity | 20~90%, non-condensing | ||||||
| Relative Humidity | 5~90%, non-condensing | ||||||
| Operating Altitude | 16,000 ft | ||||||
| Non-operating Altitude | 40,000 ft | ||||||
| Shock | 10G acceleration (11ms duration) | ||||||
| Vibration | 10~300Hz 0.5G RMS random vibration | ||||||
| Regulatory Compliance | |||||||
| EMC | FCC & CE certified | ||||||
| Safety | CE / LVD certified | ||||||
| Environment | RoHS2 & REACH compliant |
Question: Which screen/screens will have touchscreen for the MRP-k17-3 (k17TRB)? Would all 3 displays be touch screen or only the center one?
Answer: Thank you for your inquiry. We just had confirmation from the manufacture, the K117TRB would be for only one screen. However, the touch screen could go on any of the three screens.
The TRB Touch screen could also be added to a second and third screens for an additional $243.00 per screen.
Answer: Thank you for your inquiry. We just had confirmation from the manufacture, the K117TRB would be for only one screen. However, the touch screen could go on any of the three screens.
The TRB Touch screen could also be added to a second and third screens for an additional $243.00 per screen.
